Hello people! I've been on the Fediverse for couple of years now, so here's my re-#introduction

I'm Ari, better known by my tag APZ and this is my #pinball repair, #arcade and #retrogaming account. I mostly post about playing and repairing pinball machines, but I also work on #retrocomputing with all the classics.

An IT guy by day, I moonlight as a pinball arcade owner here in #finland with my partner @quester. This is purely a hobby of mine, I do this to keep my sanity and to keep pinball alive for the next generations of players. At the moment I own a bit over 30 pinball machines from 70s to 2020s.

A lot of what I do involves #electronics, #CAD for now obsolete parts and #3dprinting and tabletop #cnc to recreate them.

I love to #travel, usually to meet like-minded arcade collectors. I have a strong preference to #repair stuff instead of throwing it away. I'm a #linux user since mid-90s, having been part of #foss movement most of my life. I also edit arcade related videos.

Continued thread

​It is done. I finished making the CNC machine. It draws circuits on a copper plate, just how i wanted. It is rare for me to finish a project. I'm so incredibly happy about it :blob_melt_sob_love:
The machine is still in kind of a rough shape. I will make proper power circuit and maybe a bluetooth for serial. Other then that, it is ready to be used :bowsette_blonde:

(Part 7: Finished)

#diy #cnc #arduino #electronics

Continued thread

Okay I'm so incredibly excited to show this :bowsette_redhead_angry: The CNC machine is almost ready and here is a short video of the z axis at work, together with a 3d printed pen holding contraption (courtesy of my friend who kindly printed it for me 🥰)
I can't believe it works. Now all that remains is the software part 👀

Credits:
The 3d model used is by tranluan19 and can be found here: thingiverse.com/thing:5505579

(Part 6)

#diy #cnc #arduino #electronics

If you, like me, are trying to use a #Gorton family single-stroke typeface with a #Glowforge laser cutter (or a #CNC machine or a #Cricut or whatever), and you'd like an easy way to do type layout while keeping everything in the single-stroke vector space, it turns out there is a solution for that (!!): https://msurguy.github.io/cnc-text-tool/

If all of the above is gibberish but you're curious, basically, here's the thing:

- most vector drawing tools (I use #AffinityDesigner) will happily open & use TrueType or OpenType fonts, but their model of a "font" is typically "a closed outline stroke with a fill"
- things like laser cutters and CNC machines love paths/strokes, but they don't grok "fill" (or, in the case of modern laser cutters, they do, but it's finicky and you have to do a lot of trial-and-error tweaking to get the stroke & the fill working together so that the type renders like you want it to)
- there are quite a few sources for single-path SVGs of classic engraving fonts (including Fedi's favorite, #Gorton) but if you want to actually lay out words instead of single characters . . . lotta manual work
- the web application I linked above solves **this specific problem** by letting you do text layout, and then it outputs a single SVG that you can import into your CNC software or into your vector drawing software for integration into your designs
msurguy.github.ioCNC Text ToolHershey Text Single Stroke Text Tool for plotters and CNC Machines

Am 12. Juli gibt es einen Lasercutter Workshop. Von 15 bis 18 Uhr (open end) zeigen wir wie man mit Lasercuttern umgeht.

Vom Entwurf bis zum fertigen Werkstück ist alles dabei. Du brauchst keine Vorkenntnisse: Wir zeigen dir, was du wissen musst, um sicher und kreativ mit dem Lasercutter zu arbeiten.

Bitte melde dich über Mastodon oder unter anmeldung@makerspace-esslingen.de an.

Mehr Infos: www.essembly.de
#Makerspace #EsslingenamNeckar #EsslingenMaker #LinuxCafe #Maker #Lasercutter #CNC

I've spent the past couple hours trying to design a device to perfectly & repeatably polish an asymmetrical pen.

Was thinking threaded rod with attached polishing device following curve translated from distance from central axis + mini lathe(ish) holding pen + gears / belts + …

And then I realized I could just trick the #CNC into doing it by defining an end mill "bit" with the same dimensions as a polishing bit for a dremel.

Got the basic framing parts for the enclosure for my CNC aluminum router. It's 3' x 3' x 2' with a front door. It has an 1/8" aluminum floor. I'll need to cut it down a little to size. I have parts for a top door coming. Also, I'm thinking of splitting the front door into two sides for less leverage and less space required for opening.

Continued thread

Wiring placed on a prototype board. Both axis move! :bowsette_blonde:
I've run into problems initially, because the second chip wouldn't work no matter what I did but i finally found the issue. It was because arduino nano i'm using, specifically it's pins A6 and A7 𝗮𝗿𝗲 𝗮𝗻𝗮𝗹𝗼𝗴 𝗼𝗻𝗹𝘆 and to drive those chips, you need a digital signal. It took me an embarrassing amount of time to figure out and an unnecessary disassembly and assembly of the board. Hopefully this post will save somebody some debugging

(Part 5)

#diy #cnc #arduino #electronics

Continued thread

I've got movement! :bowsette_blonde:
I roughly connected one bridge to one axis to see if it would move at all and look at it! Look at it goooo :blob_heart_eyes:
I feel reinvigorated, I think i might actually be able to finish this project. Next up is putting all the wiring on a prototype board

(Part 4)

#diy #cnc #arduino #electronics

just came across https://grid.space/ today and it’s not going to be the best in class of any of the apps it provides in terms of functionality and polish but it sure is a powerful set of overlapping functionality in a relatively comprehensive appearing package with some high nerdery under the covers (e.g. https://grid.space/kiri/engine.html)

if you’re into #3Dprinting, #lasercutters, or desktop #CNC and might want to use a fully browser-based web app to prepare files for your machines take a look.

grid.spaceBrowser Based 3D Maker ToolsBrowser-Based Maker Tools for 3D Printing, CNC, Laser, Device Control and more
