site:
title: Daheim # display name for UI
meters:
grid: Goodwe_GW10K-ET_Wechselrichter_Netz
pv:
- Tasmota_bitShake_Smartreader_Air_PV_alt
- Goodwe_GW10K-ET_Wechselrichter_PV_neu
battery: Pylontech_Force-H3

# define your loadpoints according your needs
# see https://docs.evcc.io/en/docs/reference/configuration/loadpoints
loadpoints:
- title: Wallbox Warp3 (Garage) # display name for UI
charger: Tinkerforge_Warp3 # charger
vehicle: Cupra_Born # default vehicle
mode: "pv" # default charge mode to apply when vehicle is disconnected; use "off" to disable by default if charger is publicly available
priority: 0 # relative priority for concurrent charging in PV mode with multiple loadpoints (higher values have higher priority)

meters:
- name: Goodwe_GW10K-ET_Wechselrichter_Netz
type: template
template: goodwe-hybrid
usage: grid
modbus: tcpip
id: 247
host: 192.168.178.xx
port: 502
battery: 1 # [1, 2] (optional)
- name: Goodwe_GW10K-ET_Wechselrichter_PV_neu
type: template
template: goodwe-hybrid
usage: pv
modbus: tcpip
id: 247
host: 192.168.178.xx
port: 502
battery: 1 # Batteriespeichernummer, [1, 2] (optional)
- name: Tasmota_bitShake_Smartreader_Air_PV_alt
type: custom
power:
source: mqtt
topic: tele/tasmota_33281C/SENSOR
jq: .M60.Power # bei Übertragung von mehreren Werten
scale: -1 # da bei Einspeisung die Leistung negativ ist
timeout: 60s
energy:
source: mqtt
topic: tele/tasmota_33281C/SENSOR
jq: .M60.E_Out #bei Übertragung von mehreren Werten
timeout: 60s
- name: Pylontech_Force-H3
type: template
template: goodwe-hybrid
usage: battery
modbus: tcpip
id: 247
host: 192.168.178.xx
port: 502
battery: 1 # Batteriespeichernummer, [1, 2] (optional)

# replace with your real charger
# see https://docs.evcc.io/docs/devices/chargers
chargers:
- name: Tinkerforge_Warp3
type: template
template: tinkerforge-warp3
host: 192.168.178.xx # IP-Adresse oder Hostname, IP Adresse oder der Hostname des MQTT Brokers
port: 1883 # MQTT Broker Port
topic: warp3/2bej # Topic (ohne / am Anfang)
timeout: 60s # Zeitüberschreitung, Akzeptiere keine Daten die älter sind als dieser Wert (optional)
user: mosquitto
password: <password>

mqtt:
broker: 192.168.178.xx:1883
topic: evcc # root topic for publishing, set empty to disable
user: mosquitto
password: <passsword>

# replace with your real vehicle (optional)
# see https://docs.evcc.io/docs/devices/vehicles
vehicles:
- name: Cupra_Born
type: template
template: cupra
#user: # Benutzerkonto, bspw. E-Mail Adresse, User Id, etc.
#password: # Passwort, Bei führenden Nullen bitte in einfache Hochkommata setzen
# vin: W... # Fahrzeugidentifikationsnummer, Wenn mehrere Fahrzeuge eines Herstellers vorhanden sind (optional)
title: Cupra Born # Titel, Wird in der Benutzeroberfläche angezeigt (optional)
capacity: 58
